Deployable Vapor Sampler System (DVS)

Part Number:

100-3950

- +
Overview

DVS System includes a Leland Legacy Sample Pump with connection case and cable, charger (100-240 V), 2 external battery assemblies with adapters, a dual tube holder, 2 protective tube covers, a CPC assembly, calibration tubing, sample tubing, rain cover, and mounting bracket in a heavy-duty lockable carry case with custom foam. Requires thermal desorption tubes, purchased separately, that are compatible with the desorber in use.

The compact, portable, battery-operated SKC Deployable Vapor Sampler (DVS) System provides cost-effective vapor sampling in indoor and outdoor environments and in urban, industrial, and rural settings. The system features the fully programmable Leland Legacy Sample Pump, a specially designed dual tube holder, and other equipment needed for effective ambient vapor sampling. All components are packaged in custom foam inside an easily carried heavy-duty lockable case from which the system operates.
Attributes
Flow Rate5 to 15 L/min
Touch Screen OperationNo
Battery Type (Power)Li-ion
Approx. Run Time24+ Hours at 10 L/min
ConnectivityWith USB Cable purchased separately
PC CompatibleYes
ProgrammableYes
Compensates for Changes in Atmospheric PressureYes
Compensates for Changes in TemperatureYes
Constant FlowYes
Constant Pressure ModeNo
Automatic Flow Rate VerificationYes
Intrinsic SafetyNo
CE MarkedYes
UKCA MarkedYes


Performance Profile

System Flow Rate8 L/min
System Run Time> 24 hrs (one battery charge)
PowerRechargeable Li-Ion battery*, 7.4 V, 12-Ah capacity, 88.8 Wh
Battery Recharge Time (with SKC-approved chargers; varies with battery capacityand level of discharge) 15 hrs
Temperature RangeOperating: 32 to 104 F (0 to 40 C)
Charging: 32 to 113 F (0 to 45 C)
Storage: -4 to 95 F (-20 to 35 C)
AltitudeDo not use pump beyond 7500 ft.
Collection MediaThermal desorption sorbent tubes that are compatible with the
desorber in use
AnalysisThermal desorption followed by chemical analysis dependent
upon the analyte of interest
Case Dimensions18.5 x 14.1 x 6.9 in (47 x 36 x 18 cm)
System Weight12.8 lbs (5.8 kg)
RFI/EMI ShieldingCE marked

* Li-Ion batteries are subject to special shipping regulations.
