Part Number:
225-49K
| Cut-point | 100 μm |
|---|---|
| Flow Rate | 1 L/min |
| Disposable | No |
| Type | Inhalable Mixed-phase |
| Flow Rate | 1 L/min |
| 50% Cut-point | 100 µm at 1 L/min inhalable fraction |
Material | Sampling Head: Stainless steel front plate and filter cassette with 10.6-mm dia. inlet*; aluminum clip, housing, and outlet Tube Holder: Black rubber Protective Tube Cover: Plastic |
| Maximum Operating Temperature | 392 F (200 C) suitable for autoclaving and solvent washing |
| Filters | 25-mm glass fiber, quartz, or coated filter (see guide below) |
| Sorbent Tubes | 8 x 110-mm size. Dependent upon compound of interest (see guide below) |
| Tubing | ¼-inch ID |
| Weight | 2.4 oz (68 gm) |
| Dimensions | 8.5 x 1.2 in (21.6 x 3.17 cm) |
* Designed to meet the inhalable convention based on the scaling down technique described in the Final Report on research carried out under NIOSH-CDC Grant No. RO1-OH 03687-03, “Development of New Personal Aerosol Samplers,” Vincent, J.H., et al., 2003.
ACGIH has assigned a TLV with Inhalable Fraction and Vapor (IFV) designation to over 50 compounds that exert sufficient vapor pressure such that the contaminant may be present in both particle and vapor phases, with each phase contributing a significant portion of the dose. IFV Pro allows for efficient sampling of compounds with this designation (see guide below) or compounds found in mixed phases due to work activities or processes.
